Item Value
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
0 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 8.2 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1460 nm - 1620 nm
Rx sensitivity (AVG) [dBm] -23 dBm
Rx sensitivity (OMA) [dBm] -
Overload power (AVG) [dBm] -7 dBm
Overload power (OMA) [dBm] -
3.4.12.6 10Gbps-SFP+-SMF-1571nm-70km-commercial
Table 3-183 10Gbps-SFP+-SMF-1571nm-70km-commercial specications
Item
Value
Basic Information
Module name 10Gbps-SFP+-SMF-1571nm-70km-
commercial
Part Number 34060691
Model OSX070006
Form factor SFP+
Application standard IEEE 802.3ae, 10GBASE-X
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 236
