Item Value
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 9 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1260 nm - 1565 nm
Rx sensitivity (AVG) [dBm] -24 dBm
Rx sensitivity (OMA) [dBm] -
Overload power (AVG) [dBm] -7 dBm
Overload power (OMA) [dBm] -
NOTE
The interface standard is Huawei-specic. Self-loop is not supported. An optical attenuator
must be added if self-loop is required.
3.4.10.2 10Gbps-SFP+-SMF-1310nm-10km-industry
Table 3-171 10Gbps-SFP+-SMF-1310nm-10km-industry specications
Item
Value
Basic Information
Module name 10Gbps-SFP+-SMF-1310nm-10km-
industry
Part Number 34060599
Model OSX010N05
Form factor SFP+
Application standard IEEE 802.3ae, 10GBASE-LR/LW
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] -40°C to 85°C(-40°F to 185°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 220
