Item Value
Rx operating wavelength range [nm] 1264.5 nm ~ 1277.5 nm
1284.5 nm ~ 1297.5 nm
1304.5 nm ~ 1317.5 nm
1324.5 nm ~ 1337.5 nm
Minimum Rx optical power (AVG)
[dBm]
per lane: -7.3 dBm
Maximum Rx optical power (AVG)
[dBm]
per lane: 3.5 dBm
Maximum Rx optical power (OMA)
[dBm]
per lane: -7.6 dBm
Rx sensitivity (AVG) [dBm] per lane: -7.6 dBm
Rx sensitivity (OMA) [dBm] −4.6dBm, SECQ − 6.0dB
Overload power (AVG) [dBm] per lane: 3.5 dBm
Overload power (OMA) [dBm] -
NOTE
During link deployment, focus on the reection indicators of each node. The discrete
reection indicators must meet the IEEE specications.
IEEE 802.3cu standard discrete reection requirements: For a 400G FR4 link with six
reection points, each reection point must be less than or equal to –38 dB. For a 400G
FR4 link with eight reection points, each reection point must be less than or equal to –40
dB. For a 400G FR4 link with 10 reection points, each reection point must be less than or
equal to –41 dB.
When this type of optical module is used to interconnect with WDM equipment, the
protection switching time of WDM client-side 1+1 protection is greater than 50 ms.
3.4.20.5 400Gbps(8*50Gb/s PAM4)-QSFP-DD-MMF-850nm-0.1km-commercial
Table 3-221 400Gbps(8*50Gb/s PAM4)-QSFP-DD-MMF-850nm-0.1km-commercial
specications
Item
Value
Basic Information
Module name 400Gbps(8*50Gb/s PAM4)-QSFP-DD-
MMF-850nm-0.1km-commercial
Part Number 02313KST
Model QSFP-DD-400G-850-0.1km
Form factor QSFP-DD
Application standard IEEE802.3 bs-2017
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 293
