Appearance

Figure 3-33 Appearance of the FAN-180D-F

Version Mapping

Table 3-83 Mappings between FAN-180D-F and product

Product

First

Supported

Version

Unsupported

Model

Limitations IDs of

available

slots

NetEngine

8000

F2A-8K36H

V800R021C00

SPC100

CR8P0BKP03C

- 4–6

HUAWEI NetEngine 8000 F

Hardware Guide 3 Hardware Description
