Item Value
Module name 155Mbps-eSFP-SM-1310nm(Tx)/
1550nm(Rx)-15km-commercial
Part Number 02310QNG
Model OSC015B01
Form factor eSFP
Application standard IEEE 802.3, 100BASE-BX10-U
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 155 Mbit/s
Target transmission distance [km] 15 km
Transmitter Optical Characteristics
Center wavelength [nm] 1310 nm
Tx operating wavelength range [nm] 1260 nm - 1360 nm
Maximum Tx optical power (AVG)
[dBm]
-8 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-14 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 8.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1480 nm - 1580 nm
Rx sensitivity (AVG) [dBm] -32 dBm
Rx sensitivity (OMA) [dBm] -
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 134
