Item Value
Part Number 34060286
Model eSFP-850nm-1000Base-Sx/FC200MM
Form factor eSFP
Application standard IEEE 802.3, 1000BASE-SX
Connector type LC
Optical ber type MMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] -20°C to 85°C(-4°F to 185°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 1.25 Gbit/s
Target transmission distance [km] 0.5 km(OM1)
Transmitter Optical Characteristics
Center wavelength [nm] 850 nm
Tx operating wavelength range [nm] 770 nm - 860 nm
Maximum Tx optical power (AVG)
[dBm]
0 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-9.5 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 9 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 760 nm - 860 nm
Rx sensitivity (AVG) [dBm] -17 dBm
Rx sensitivity (OMA) [dBm] -
Overload power (AVG) [dBm] 0 dBm
Overload power (OMA) [dBm] -
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 139
