Huawei NetEngine 8000 F

To Next Page

To Previous Page

Description Part Number Model First

supported

version

Integrated

xed device

NetEngine

8000

F1A-8H20Q

Integrated

Chassis

Components(

Port-side

Intake)

02355KVX CR8B0BKP03

V800R022C10

SPC500

NetEngine

8000

F1A-8H20Q

Integrated

Chassis

Components(

Port-side

Exhaust)

02355KVY CR8B0BKP03

V800R022C10

SPC500

Appearance

Figure 3-1 Appearance of the NetEngine 8000 F1A-8H20Q (port side)

HUAWEI NetEngine 8000 F

Hardware Guide 3 Hardware Description
