Item Value
Application standard IEEE 802.3ae, 10GBASE-ER/EW
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] -40°C to 85°C(-40°F to 185°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 9.953 Gbit/s
10.3125 Gbit/s
Target transmission distance [km] 40 km
Transmitter Optical Characteristics
Center wavelength [nm] 1550 nm
Tx operating wavelength range [nm] 1530 nm - 1565 nm
Maximum Tx optical power (AVG)
[dBm]
4 dBm
Maximum Tx optical power (OMA)
[dBm]
-1.7 dBm
Minimum Tx optical power (AVG)
[dBm]
-4.7 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 3 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1530 nm - 1565 nm
Rx sensitivity (AVG) [dBm] -15.8 dBm
Rx sensitivity (OMA) [dBm] -14.1 dBm
Overload power (AVG) [dBm] -1 dBm
Overload power (OMA) [dBm] -
NOTE
Self-loop is not supported. An optical attenuator must be added if self-loop is required.
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 222
