Item Value
Module name 40Gbps(4*10.3)-QSFP+-
MMF-850nm-0.1km-commercial
Part Number 02310WUU
Model OMXD30010
Form factor QSFP+
Application standard IEEE 802.3ba, 40GBASE-SR4
Connector type MPO-12
Optical ber type MMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8436
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 41.25 Gbit/s
Target transmission distance [km] 0.1 km(OM3)
0.15 km(OM4)
Transmitter Optical Characteristics
Center wavelength [nm] 850 nm
Tx operating wavelength range [nm] 840 nm - 860 nm
Maximum Tx optical power (AVG)
[dBm]
per lane: 0.5 dBm
Maximum Tx optical power (OMA)
[dBm]
per lane: 3 dBm
Minimum Tx optical power (AVG)
[dBm]
per lane: -7.6 dBm
Minimum Tx optical power (OMA)
[dBm]
per lane: -5.6 dBm
Minimum extinction ratio [dB] 3 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 840 nm - 860 nm
Rx sensitivity (AVG) [dBm] -
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 257
