Item Value
Application standard IEEE 802.3bm-2015, 50GBASE-BR10
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12(after FEC)
<2x10E-4(before FEC)
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 53.125 Gbit/s
Target transmission distance [km] 10 km
Transmitter Optical Characteristics
Center wavelength [nm] 1271 nm
Tx operating wavelength range [nm] 1264.5 nm - 1277.5 nm
Maximum Tx optical power (AVG)
[dBm]
4.2 dBm
Maximum Tx optical power (OMA)
[dBm]
4 dBm
Minimum Tx optical power (AVG)
[dBm]
-4.5 dBm
Minimum Tx optical power (OMA)
[dBm]
-1.5 dBm
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1324.5 nm - 1337.5 nm
Rx sensitivity (AVG) [dBm] -
Rx sensitivity (OMA) [dBm] -8.9 dBm
Overload power (AVG) [dBm] 4.2 dBm
Overload power (OMA) [dBm] -
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 268
