Item Value
Model OMND10N13
Form factor QSFP28
Application standard IEEE 802, 3bm, 100GBASE-SR4
Connector type MPO-12
Optical ber type MMF
Bit error ratio (BER) <5x10E-5
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 103.125 Gbit/s
Target transmission distance [km] 0.07 km(OM3)
0.1 km(OM4)
Transmitter Optical Characteristics
Center wavelength [nm] 850 nm
Tx operating wavelength range [nm] 840 nm - 860 nm
Maximum Tx optical power (AVG)
[dBm]
per lane: 2.4 dBm
Maximum Tx optical power (OMA)
[dBm]
per lane: 3 dBm
Minimum Tx optical power (AVG)
[dBm]
per lane: -8.4 dBm
Minimum Tx optical power (OMA)
[dBm]
per lane: -8.4 dBm
Minimum extinction ratio [dB] 2 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 840 nm - 860 nm
Rx sensitivity (AVG) [dBm] -
Rx sensitivity (OMA) [dBm] per lane: -10.3 dBm
Overload power (AVG) [dBm] per lane: 2.4 dBm
Overload power (OMA) [dBm] -
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 273
