Port Connector Type Description Available
Components
TOD clock
interface
RJ45 Port for inputting
and outputting
one-channel 1PPS
+TOD time signals
or one-channel
DCLS signals
120-ohm clock
cable
CLK interface RJ45 Port for inputting
and outputting 2
Mbit/s or 2 MHz
clock signals
120-ohm clock
cable
USB Type A USB port
(reserved)
NA
Interface Numbering Rules
On the NetEngine 8000 F1A-8H20Q, an interface is numbered in the format of
"slot number/subcard number/port number". The following part describes the
details:
● Slot number
The slot number of NetEngine 8000 F1A-8H20Q is always 0.
● Subcard number
The NetEngine 8000 F1A-8H20Q does not support subcards. Therefore, the
subcard number of the NetEngine 8000 F1A-8H20Q is
xed as 1.
● Port number
The port numbers of service interfaces on the NetEngine 8000 F1A-8H20Q
begin with 0. Port numbering depends on the number of interfaces on the
NetEngine 8000 F1A-8H20Q.
Figure 3-5 Port number
