Item Value
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 103.125 Gbit/s
Target transmission distance [km] 10 km
Transmitter Optical Characteristics
Center wavelength [nm] 1295.56 nm
1300.05 nm
1304.58 nm
1309.14 nm
Tx operating wavelength range [nm] 1294.53 nm - 1296.59 nm
1299.02 nm - 1301.09 nm
1303.54 nm - 1305.63 nm
1308.09 nm - 1310.19 nm
Maximum Tx optical power (AVG)
[dBm]
per lane: 4.5 dBm
Maximum Tx optical power (OMA)
[dBm]
per lane: 4.5 dBm
Minimum Tx optical power (AVG)
[dBm]
per lane: -4.3 dBm
Minimum Tx optical power (OMA)
[dBm]
per lane: -1.3 dBm
Minimum extinction ratio [dB] 4 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1294.53 nm - 1296.59 nm
1299.02 nm - 1301.09 nm
1303.54 nm - 1305.63 nm
1308.09 nm - 1310.19 nm
Rx sensitivity (AVG) [dBm] -
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 283
