Item Value
Module name 400Gbps-QSFP-DD-
SMF-1528.773~1567.133nm-
commercial
Part Number 02313GSB
Model OSK080N03
Form factor QSFP-DD
Application standard IEEE802.3 cw
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-15(after FEC)
<1.25E-2(before FEC)
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options QSFP-DD MSA
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 478.75 Gbit/s
Target transmission distance [km] 80 km
Transmitter Optical Characteristics
Center wavelength [nm] 1528.773nm~1567.133nm
Tx operating wavelength range [nm] 1528.773nm~1567.133nm
Maximum Tx optical power (AVG)
[dBm]
-6 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-10 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] -
Modulation mode 400G DP-16QAM
Number of tunable channels 48/64
Channel spacing [GHz] 75GHz/100GHz
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 290
