Item Value
Maximum Tx optical power (AVG)
[dBm]
-6 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-10 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] -
Modulation mode 400G DP-16QAM
Number of tunable channels -
Channel spacing [GHz] -
Center frequency deviation [GHz] ±1.8 GHz
Tx channel tuning time [s] 180s
Output optical power in case of laser
shutdown [dBm]
≤-20 dBm
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1547.715 nm
Rx sensitivity (OMA) [dBm] -
Overload power (AVG) [dBm] 0 dBm
Overload power (OMA) [dBm] -
FEC mode CFEC
RS-FEC
Rx optical power range [dBm] -12 dBm ~ 0 dBm: OSNR>=26dB
-20 dBm ~ 0 dBm: OSNR>=34dB
Minimum OSNR (back-to-back&EOL)
[dB]
26 dB
PMD tolerance [ps] 10 ps@0.5 dB OSNR penalty
PDL tolerance [dB] 2.5 with ≤ 0.8 dB OSNR penalty
SOP tolerance [krad/s] 50 krad/s@0.3dB penalty
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 296
