If no special requirements are imposed on power cables, power cables are
delivered according to default congurations. Otherwise, power cables need to be
purchased locally.
If the Power Distribution Frame (PDF) is more than 25 m (82 ft.) away from the
device, install the PDF as near as possible.
Overview
A DC power cable is used to connect to the power modules to supply power to the
device.
Cable colors below are for reference only. The actual cable colors depend on the
requirements of the target country or customer.
Appearance
Figure 3-50 DC power cable
Figure 3-51 DC power connector
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 301
