Item Specication
Rated output power [W] DC: 1000 W
AC: 600 W
AC: 1200 W
Maximum input cable size [mm²] DC:4mm^2 (1-14 meters), 6mm^2
(15-21 meters), 10mm^2 (22-35
meters)
AC:2.5mm^2
Front-end circuit breaker/fuse [A] DC:≥32A
AC:≥10A
Heat dissipation mode Air cooling
Airow direction Front to back: port-side intake
Noise at normal temperature (acoustic
power) [dB(A)]
< 72 dB (meeting the ETSI 72 dBA
standard)
Number of slots 7
Number of service board slots 1
Switching capacity 2.4 Tbit/s
Redundant power supply 1+1
Redundant fans 3+1,Short-term running when a single
fan becomes invalid at the ambient
temperature of 40°C (104°F)
Long-term operating temperature
[°C(°F)]
Port-side Intake:-5°C ~ 45°C(23°F to
113°F)
Restriction on the operating
temperature variation rate [°C(°F)]
≤ 30°C/hour (54°F/hour)
Storage temperature [°C(°F)] -40°C ~ 70°C(-40°F to 158°F)
Long-term operating relative humidity
[RH]
5% to 90% RH, non-condensing
Short-term operating relative humidity
[RH]
5% to 95% RH, non-condensing
Storage relative humidity [RH] 5% to 95% RH, non-condensing
Long-term operating altitude [m(ft.)] < 4000 m (< 13123.4 ft.)
Storage altitude [m(ft.)] < 5000 m(< 16404.2 ft.)
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 21
