Huawei NetEngine 8000 F User Manual

Item Specication
Power supply mode ● DC
● AC/HVDC
Rated input voltage [V] DC: -48 V/-60 V
AC: 100–240 V AC, supporting 240 V
HVDC
Input voltage range [V] DC: –40 V to –72 V
AC: 90 V to 290 V
Maximum input current [A] DC: 30 A
AC: 8 A
Rated output power [W] DC: 1000 W
AC: 600 W
Maximum input cable size [mm²] DC: 4 mm^2 (1-14 m), 6 mm^2 (15-21
m), 10 mm^2 (22-35 m)
AC: 2.5 mm^2
Front-end circuit breaker/fuse [A] DC: ≥ 32 A
AC: ≥ 10 A
Heat dissipation mode Air cooling
Airow direction Front to back: port-side intake
Noise at normal temperature (acoustic
power) [dB(A)]
< 72 dB (meeting the ETSI 72 dBA
standard)
Number of slots 7
Number of service board slots 1
Switching capacity 2.4 Tbit/s
Redundant power supply 1+1
Redundant fans 3+1,Short-term running when a single
fan becomes invalid at the ambient
temperature of 40°C (104°F)
Long-term operating temperature
[°C(°F)]
Port-side Intake:-5°C ~ 45°C(23°F to
113°F)
Restriction on the operating
temperature variation rate [°C(°F)]
≤ 30°C/hour (54°F/hour)
Storage temperature [°C(°F)] -40°C ~ 70°C(-40°F to 158°F)
Long-term operating relative humidity
[RH]
5% to 90% RH, non-condensing
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 23
