Huawei NetEngine 8000 F User Manual

Cable Pinouts
Table 3-246 Pin assignment of the straight-through cable connector
Connector X1 Pin Connector X2 Pin Color Relation
X1.1 X2.1 White-orange Twisted pair
X1.2 X2.2 Orange
X1.3 X2.3 White-green Twisted pair
X1.6 X2.6 Green
X1.4 X2.4 Blue Twisted pair
X1.5 X2.5 White-blue
X1.7 X2.7 White-brown Twisted pair
X1.8 X2.8 Brown
Table 3-247 Pin assignment of the crossover cable connector
Connector X1 Pin
Connector X2 Pin Color Relation
X1.1 X2.3 White-orange Twisted pair
X1.2 X2.6 Orange
X1.3 X2.1 White-green Twisted pair
X1.6 X2.2 Green
X1.4 X2.4 Blue Twisted pair
X1.5 X2.5 White-blue
X1.7 X2.7 White-brown Twisted pair
X1.8 X2.8 Brown
Technical
Specications
Table 3-248 Technical specications of the straight-through cable
Descr
iptio
n
Twisted-Pair Cable, 100ohm, Category 5e, STP, 0.52mm, 24AWG, 8Cores,
4Pairs, PANTONE 430U
Conn
ector
X1
Network Interface Connector, 8-Bit 8PIN, Shielded, Crystal Model
Connector, 24-26AWG, Leads Single Solide Cable
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 330
