X1 Pin X2 Pin
3 3B
4 4B
9 4A
10 3A
11 2A
12 1A
NO TE
If the X1 end interface is Down but the X2 end interfaces are Up, check the X1 end status.
● Check whether the X1 end interface supports the breakout function. If the X1 end
interface does not support the breakout function, replace it with another interface that
supports the breakout function.
● Check whether the X1 end interface is in the breakout state. If the X1 end interface is
not in the breakout state,
congure the interface to be in the breakout state.
Technical Specications
Table 3-252 Breakout bers supported
Part
Numbe
r
Model Description Mode
141325
37-005
SS-OP-
MPO12-4*DLC-
M-15B
Optical Cable Parts,MPO/PC,
4DLC/PC,MULTI-MODE,15m,8
CORES,0/1m,GJFH-8A1A.
2(OM3),3.5mm,2mm,LSZH,
43MM SHORT MPO,BENDING
INSENSITIVE
Multimode
141325
37-006
SS-OP-
MPO12-4*DLC-
M-30
Optical Cable Parts,MPO/PC,
4DLC/PC,MULTI-MODE,30m,8
CORES,0/1m,GJFH-8A1A.
2(OM3),3.5MM,2mm,LSZH,
43MM SHORT MPO,BENDING
INSENSITIVE
Multimode
141325
38
MPO12-4DLC-
SM-15
Optical Cable Parts,MPO/APC,
4DLC/PC,Single mode,15m,8
cores,0m/1m,GYFH-8G.
657A2,3.5mm,2mm,LSZH,
43mm short MPO,Bending
insensitive
Single-mode
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 337
