Huawei NetEngine 8000 F User Manual

Breakout Fiber Optical Module Board
[14132538/
MPO12-4DLC-SM-15]
Optical Cable
Assembly,MPO/APC,
4*DLC/
PC,Singlemode,GJFH 8G.
657A2(LSZH),15m,
3.5mm,8 Cores,0m/1m,
2mm
[14132537/SS-OP-
MPO12-4*DLC-M-5]
Optical Cable
Parts,MPO/PC,4DLC/
PC,Multi-mode,5m,8
cores,0/1m,GJFH-8A1a.
2(OM3),3.5mm,
2mm,LSZH,43mm Short
MPO,Bending insensitive
[02310WUU/
OMXD30010] Optical
Transceiver,QSFP+,
850nm,
41.25Gbps,-7.6dBm,-1dB
m,-9.5dBm,MPO,MMF,
0.15km
[14132537-005/SS-OP-
MPO12-4*DLC-M-15B]
Optical Cable
Parts,MPO/PC,4DLC/
PC,Multi-mode,15m,8
cores,0/1m,GJFH-8A1a.
2(OM3),3.5mm,
2mm,LSZH,43mm Short
MPO,Bending insensitive
[14132537-006/SS-OP-
MPO12-4*DLC-M-30]
Optical Cable
Parts,MPO/PC,4DLC/
PC,MULTI-MODE,30m,8
CORES,0/1m,GJFH-8A1A.
2(OM3),3.5MM,
2mm,LSZH,43MM
SHORT MPO,BENDING
INSENSITIVE
[14132537-001/SS-OP-
MPO12-4*DLC-M-100]
Optical Cable
Parts,MPO/PC,4DLC/
PC,Multi-mode,100m,8
cores,0/1m,GJFH-8A1a.
2(OM3),3.5mm,
2mm,LSZH,43mm Short
MPO,Bending insensitive
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 341
