Distance
Between
Front and
Rear
Mounting
Rails
Installation of Front Mounting Brackets, Rear Mounting
Brackets, and Rear Mounting Bracket Guide Rails
638 mm to
696 mm
697 mm to
835 mm
7. Use a torque screwdriver to install the extension runners of the expandable
mounting brackets on the rear posts of the cabinet using M6 screws with a
torque of 3 N m. Horizontally insert the chassis into the cabinet from the
front of the cabinet until the extension rails are fully inserted into the
extension runners. Then, use screws to
x the front mounting brackets to the
cabinet.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 413
