Drag the ber end face on the same area in the lens tissue only once.
Otherwise, the connector can be contaminated or damaged.
Figure 4-247 Cleaning the ber end face using the lens tissue on the desk
Figure 4-248 Cleaning the ber end face using the lens tissue on the hand
5. Repeat 4 several times on the areas of the lens tissue that have not been
used.
6. Use the compressed air to blow
o dust on the ber end face.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 598
