Figure 4-302 Rotating the cover plate
6. Check whether cable installation is qualied.
NO TICE
● Power wires must be properly installed, as shown in Figure 4-303. If you
can see the internal copper wires when pulling the power cable, the
installation is
unqualied, as shown in Figure 4-304.
● After tightening the screws, ensure that the cover plate is rotated to the
required position to completely cover the screws, as shown in Figure
4-305. Otherwise, the screws are still exposed to some extent, as shown in
Figure 4-306.
● You can check whether the copper wires have been tightly crimped via the
viewing window, as shown in Figure 4-307. If the outer jacket of the cable
can be seen via the viewing window, the cable installation is
unqualied,
as shown in Figure 4-308 and Figure 4-309.
