Huawei NetEngine 8000 F User Manual

Panel
Table 3-49 Indicators on the PDC1000S12-CB
Silkscreen Name Color Status Description
STAT Working
status
indicator
Green Steady on the power
input is
normal.
- O the power
module is
switched o
or the
hardware of
the power
module is
faulty.
Table 3-50 Ports on the PDC1000S12-CB
Port
Description
NEG(-) Connects to the negative pole of the
DC power cable.
RTN(+) Connects to the positive pole of the
DC power cable.
Technical
Specications
Table 3-51 Technical specications of the PDC1000S12-CB
Item
Specication
Dimensions without packaging (H x W
x D) [mm(in.)]
39.8 mm x 90 mm x 214.5 mm (1.57
in. x 3.54 in. x 8.44 in.)
Weight without packaging [kg(lb)] 0.87 kg(1.92 lb)
Rated input voltage [V] –48 V/–60 V
Input voltage range [V] –40 V to –72 V
Maximum input current [A] 30 A
Rated output voltage [V] 12 V
Rated output current [A] 83.3 A
Rated output power [W] 1000 W
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 72
