2.10 Lift Bars and Swivel Hoist Rings
Every mold and hot runner assembly is equipped with tapped lift holes for lifting either the
complete assembly or individual plates. Husky only supplies special lifting equipment (including a
lift bar and swivel hoist rings) when required. This lifting equipment is designed specically for
the mold/hot runner assembly. When Husky provides special lifting equipment, use only Husky
specied and supplied lifting equipment.
NOTE:
Separate lift bars for the hot and cold halves of the mold and hot runner assembly may be
provided based on the requirements of the assembly.
IMPORTANT!
Make sure all lifting equipment is rated for the load and in safe operating condition. Follow the
recommendations and use care when moving or handling plates or assemblies.
For instructions about lifting plates and plate assemblies and using the Husky provided lift bar
and swivel hoist rings, refer to Section 4.1.
NOTE:
The Husky provided lift bar, swivel hoist rings and associated hardware must be stored together
while the mold, hot runner, tooling plate and CoolPik plate are in operation.
Hot Runner Installation Manual v 2.2 — March 2021 Safety Summary
Lift Bars and Swivel Hoist Rings 27
