Husky Unify - Installing and Removing the Manifold Assembly; Installing the Manifold into the Plates

Table 4-2: Specications for Metric Coarse Swivel Hoist Rings
Part Number Rated Capacity
[1]
Torque Thread Ø
Minimum Full
Thread Depth
Pitch
2761800 1050 kg (2315 lb) 37 N·m (27 lbf·ft) M12 24 1.75
2770570 1900 kg (4189 lb) 80 N·m (59 lbf·ft) M16 32 2.00
2502267 4200 kg (9259 lb) 311 N·m (229 lbf·ft) M24 48 3.00
536013 7000 kg (15432 lb) 637 N·m (470 lbf·ft) M30 60 3.50
2761801 11000 kg (24250 lb) 1085 N·m (800 lbf·ft) M36 72 4.00
2761803 12500 kg (27558 lb) 1085 N·m (800 lbf·ft) M42 84 4.50
[1]
Minimum rated capacity at any pull angle (between 0° horizontal pull and 90° vertical pull)
Table 4-3: Specications for Inch UNC Swivel Hoist Rings
Part Number Rated Capacity
[2]
Torque Thread Ø
Minimum Full
Thread Depth
Pitch
2732764 1130 kg (2500 lb) 38 N·m (28 lbf·ft) 1/2 1.0 13
2732765 2260 kg (5000 lb) 135 N·m (100 lbf·ft) 3/4 1.5 10
2760517 4530 kg (10000 lb) 310 N·m (229 lbf·ft) 1 2.0 8
2732766 6800 kg (15000 lb) 640 N·m (472 lbf·ft) 1 1/4 2.5 7
2732767 10880 kg (24000 lb) 1080 N·m (797 lbf·ft) 1 1/2 3.0 6
[2]
Minimum rated capacity at any pull angle (between 0° horizontal pull and 90° vertical pull)
4.2 Installing and Removing the Manifold Assembly
Use the following procedures to install and remove the Unify manifold assembly to the mold.
4.2.1
Installing the Manifold into the Plates
To install the Unify manifold into the plates, do the following:
1. Install the assembly guide rods into the tapped holes in the manifold plate pocket. Refer to
the assembly drawing for the location of the tapped holes.
2. Install hoist rings to the designated lifting points on the manifold face. Refer to the assembly
drawing for the location of the lifting points.
3. Attach the hoist rings to an overhead lifting device and lift the manifold only until the lifting
chain has a slight tension on it.
