Table 3-2: Small Hydraulic Actuator Components (Continued)
Item Component Description Quantity
2 SHCS M6 x 25 mm (1 in) 2
3 Cylinder Standard Stroke 1
Short Stroke (APP) 1
4 Adapter tting JIC AN4 to NPT for Hydraulic 2
5 Adapter tting JIC AN5 to NPT for Water 2
6 Wear Ring 1
7 Piston Seal 1
8 Piston Standard Stroke 1
Short Stroke (APP) 1
9 Seal Cap 1
10 Step Seal 1
11 Scraper Seal 1
12 O-Ring 1
13 Cylinder Base Standard Stroke 1
Short Stroke (APP) 1
14 Spring Pin S/A 1
15 Seal insert 1
16 Seal insert 1
