Husky Unify - Piston Seal; Piston

Table 3-4: Large and Small Pneumatic Actuator with Thermal Regulator Components (Continued)
Item Component Description Actuator Size Quantity
3 Cylinder Cap Small 1
Large 1
4 Gasket Small 1
Large 1
5 Adapter tting JIC AN4 to NPT for Air 2
6 Piston Seal Small 1
Large 1
7 O Ring Small 1
Large 1
8 Piston Small (12.4 mm stroke) 1
Large (13.58 mm stroke) 1
9 GLYD Ring 1
10 O Ring 1
11 Cylinder Small 1
Large 1
12 Spring Pin S/A 1
13 Thermal Regulator Small 1
Large 1
14 Disc Spring Small 1
Large 1
Hot Runner Installation Manual v 2.2 — March 2021 Specications
Hydraulic and Pneumatic Actuator Component Specications 41
