WARNING!
Crushing hazard – risk of death or serious injury. Inadequate lifting equipment can fail and
could cause death or serious injury. Make sure all lifting equipment is rated for the load and
in safe operating condition.
8. Attach an overhead lifting device to the hoist rings and lift only until the lifting chain has a
slight tension on it.
CAUTION!
Mechanical hazard – risk of damage to equipment. When storing the hot runner, make sure
it is secured in the vertical or horizontal position. Do not rest the assembly against another
object.
CAUTION!
Mechanical hazard – risk of damage to the hot runner. The hot runner must be set on
supports if it is laid down horizontally, such as on a work bench. Damage to the nozzle tips,
sprue bushing and/or wires could occur.
9. Move the manifold assembly to a safe location.
10. Remove the hoist rings from the designated lifting points on the manifold assembly.
Hot Runner Installation Manual v 2.2 — March 2021 Installation and Removal
Installing and Removing the Manifold Assembly 53
