Chapter 5 I/O Parameter
106
I/O Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
225 Extension I/O control 0H 0H ~ FFFFFFFFH
Bits 0 to 3: I/O2 Module Type
( 0: Not mounted
1: CC-Link,
2: DeviceNet,
3: PROFIBUS,
4: IA-NET
5 to 6: System reservation
7: EtherNet/IP,
8: System reservation
9: PIO)
Bits 4 to 7:
System reservation
226 I/O2 fieldbus node address 0 0 ~ 99999999
• When CC-Link: 1 to 64
• When DeviceNet: 0 to 63
• When PROFIBUS: 0 to 125
227
I/O2 fieldbus communication
speed
0 0 ~ 9
• When CC-Link:
(0: 156kbps, 1: 625kbps, 2: 2.5Mbps, 3: 5Mbps, 4:
10Mbps)
• When DeviceNet:
(0: 125kbps, 1: 250kbps, 2: 500kbps, 3: Auto)
• When EtherNet/IP:
(0: Auto negotiation, 1: 10Mbps (Half-duplex), 2: 10Mbps
(Full-duplux), 3: 100Mbps (Half-duplex), 4: 100Mbps
(Full-duplux))
* Setting unnecessary when PROFIBUS
228 (For extention) 0
229 (For extention) 0
230 (For extention) 0
231 System reservation 0 0 ~ 240
232 System reservation 0 0 ~ 240
233 System reservation -1 -1 ~ 299
234 System reservation -1 -1 ~ 599
235 System reservation 0 0 ~ 5
236 (For extention) 0
237 System reservation 0 0 ~ 99999999
238 System reservation 0 0 ~ 9
239 (For extention) 0
240 (For extention) 0
241 (For extention) 0
242 (For extention) 0
243 (For extention) 0
244 (For extention) 0
245 (For extention) 0
246 (For extention) 0
247 (For extention) 0
248 (For extention) 0
249 (For extention) 0
250 (For extention) 0
251 (For extention) 0
252 (For extention) 0
253 (For extention) 0
254 (For extention) 0
255 (For extention) 0
256 (For extention) 0
257 (For extention) 0
258 (For extention) 0
259 (For extention) 0
260 (For extention) 0
261 (For extention) 0
262 (For extention) 0
263 (For extention) 0
264 (For extention) 0
265 (For extention) 0
266 (For extention) 0
267 (For extention) 0
268 (For extention) 0
269 (For extention) 0
270 (For extention) 0
271 (For extention) 0
272 (For extention) 0
273 (For extention) 0
