Chapter 1 Specications Check
23
Chapter 1 Specifications Check
1.1 Product Check
The standard configuration of this product is comprised of the following parts.
If you find any faulty or missing parts, contact your local IAI distributor.
1.1.1 Parts (Excluding Options)
No. Part Name Model
Quantity
1 Controller Main Body
Refer to “How to read the model plate”, “How to read the
model”. [Refer to 1.1.4 or 1.1.5.]
1
Accessories
2 System I/O Plug DFMC1.5/6-ST-3.5 (Supplier: PHOENIX CONTACT) 1
3 AC Power Plug
MSTB2.5/3-STF-5.08 (SK: N-PE)
(Supplier: PHOENIX CONTACT)
1
4
Motor Drive Power
Line Connector
FKIC2.5HC/2-ST-5.08 (Supplier: PHOENIX CONTACT) 1
5 Dummy Plug DP-4S (Enclosed in PG, PGF or PGX) 1
6 I/O Flat Cable
CB-PAC-PIO□□□ □□□ shows the cable length
(Example) □□□ : 020 = 2m
(In common for both standard I/O and extension I/O (PIO
type))
1 or 2
(for number of
mounted PIO)
Model CC: MSTB2.5/5-STF-5.08AU
(Supplier: PHOENIX CONTACT)
7 CC-Link Connector
Model CC2: TMSTBP2.5/5-STF-5.08 AUBD-FG
(Supplier: PHOENIX CONTACT)
1
Model DV: MSTB2.5/5-STF-5.08AUM
(Supplier: PHOENIX CONTACT)
8 DeviceNet Connector
Model DV2: TMSTBP2.5/5-STF-5.08 AUM
(Supplier: PHOENIX CONTACT)
1
9 First Step Guide 1
10
Instruction Manual
(DVD)
1
11 Safety Guide 1
1.1.2 Teaching Tool (Optional)
A teaching tool such as PC software is necessary when performing the setup for creating a
program, position setting and parameter setting, etc. that can only be done on the teaching tool.
Please prepare either of the following teaching tools.
No. Part Name Model
1
PC Software (with RS232C Cable + Connector Conversion Cable ･ with Emergency
Stop Box)
IA-101-X-MW-JS
2 PC Software (with USB Cable (CB-SEL-USB030) + Dummy Plug (DP-4S)) IA-101-X-USBS
3 Teaching Pendant TB-02
4 Teaching Pendant TB-01
