Chapter 5 I/O Parameter
137
Other Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
47 Other setting bit pattern 2 1H 0H ~ FFFFFFFFH
Bits 0 to 3: Calendar function use selection
(0: Not in use
1: Use
2: Not in use (Use the elapsed time after the
reset)
3: System reservation)
* Clear all data in error list when making
change
Bits 4 to 7: 7-segment display factor switchover
(0: Valid, 1: Invalid)
* Display is switched among emergency stop
/ ENB / cold-start, operation cancel level
error.
Bits 8 to 11: Use servo monitor IO monitoring function
(0: Not in use, 1: Use)
Bits 12 to 15: Program 7SEG display class during
execution
(0: Displays final program number,
1: Displays the program number booted the
first)
Bits 16 to 19: (PCX/PGX) System reservation
(PC/PG/PCF/PGF)
Select PARG acquiring angle coordinate
direction
(0: CW 1: CCW)
(Main application V2.00 or later)
Bits 20 to 31: For future extension
48 (For extension) 0
49 (For extension) 0
50 (For extension) 0
51 (For extension) 0
52 (For extension) 0
53 Fan status monitoring setting 1 1H 0H ~ FFFFFFFFH
Bit 0 : Monitoring status of fan 1
(0: Invalid, 1: Valid)
Bits 1 to 31: System reservation
54 Fan status monitoring setting 2 0H 0H ~ FFFFFFFFH
Bits 0 to 15: System reservation
Bits 16 to 19: Fan status monitoring error level
(0: Message level, 1: Cold-start level)
Bits 20 to 31: System reservation
55 PC/TP data protect setting 1 0H 0H ~ FFFFFFFFH
Bits 0 to 3: Protect type (Program)
(0: Read/write
1: Read only
2: No read/write)
Bits 4 to 7: Protect release method (Program)
(0: Special operation)
Bits 8 to 11: Protect type (Position)
(0: Read/write
1: Read only
2: No read/write)
Bits 12 to 15: Protect release method (Position)
(0: Special operation)
Bits 16 to 19: Protect type (Symbol)
(0: Read/write
1: Read only
2: No read/write)
Bits 20 to 23: Protect release method (Symbol)
(0: Special operation)
Bits 24 to 27: Protect type (Parameter)
(0: Read/write
1: Read only
2: No read/write)
Bits 28 to 31: Protect release method (Parameter)
(0: Special operation)
* Referenced by the PC/TP
56 PC/TP data protect setting 2 0H 0H ~ FFFFFFFFH
Bits 0 to 3: Protect range maximum number (Program)
(1’s place, BCD)
Bits 4 to 7: Protect range maximum number (Program)
(10’s place, BCD)
Bits 8 to 11: Protect range maximum number (Program)
(100’s place, BCD)
Bits 12 to 15: Protect range minimum number. (Program)
(1’s place, BCD)
Bits 16 to 19: Protect range minimum number. (Program)
(10’s place, BCD)
Bits 20 to 23: Protect range minimum number. (Program)
(100’s place, BCD)
Bits 24 to 31: System reservation
* Referenced by the PC/TP
