Chapter 5 I/O Parameter
136
Other Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
21 Manual operation type 0 0 ~ 5
0: Always enable edit and SIO/PIO start (Initial condition
after connection = With safety speed)
1: Select edit and start (with password) (EU, etc.)
2: Always enable edit and SIO/PIO start (Initial condition
after connection = Without safety speed (Cancellation))
* Referenced by the PC/TP.
22 Control use region 0 0 ~ 99 0: J, 1: E, 2: EU
23 PSIZ command function type 0 0 ~ 5
0: Maximum position data area number
1: Number of position data use
24
Local variable number for
storing SEL communication
command return code
99
1 ~ 99, 1001 ~
1099
25 (For extension) 0
26 (For extension) 0
27 (For extension) 0
28 (For extension) 0
29 (For extension) 0
30 Option password 00 0H 0H ~ FFFFFFFFH
* Change is prohibited unless instructed by the
manufacturer.
31 Option password 01 0H 0H ~ FFFFFFFFH
Reserved (Change prohibited)
* Change is prohibited unless instructed by the
manufacturer.
32 Option password 02 0H 0H ~ FFFFFFFFH
Reserved (Change prohibited)
* Change is prohibited unless instructed by the
manufacturer.
33 (For extension) 0H 0H ~ FFFFFFFFH
34 (For extension) 0H 0H ~ FFFFFFFFH
35 (For extension) 0H 0H ~ FFFFFFFFH
36 (For extension) 0H 0H ~ FFFFFFFFH
37 (For extension) 0H 0H ~ FFFFFFFFH
38 (For extension) 0H 0H ~ FFFFFFFFH
39 (System reservation) 0H 0H ~ FFFFFFFFH
40 System reservation 3H 0H ~ FFFFFFFFH For adjustment by the manufacture
41 System reservation 80H 0H ~ FFFFFFFFH For adjustment by the manufacture
42 System reservation 7H 0H ~ FFFFFFFFH For adjustment by the manufacture
43 Special monitor type 0H 0H ~ FFFFFFFFH
* Change is prohibited unless instructed by the
manufacturer.
44 (For extension) 0H 0H ~ FFFFFFFFH
45 Special start condition setting 0H 0H ~ FFFFFFFFH
Bits 0 to 3: Enable start from PC/TP in AUTO mode =
Used exclusively by the manufacturer
(0: Do not permit, 1: Permit)
Bits 4 to 7: PIO program start (Input port 000)
Single start selection
(0: Normal, 1: Single start)
* When single start is selected, the next PIO
program start (input port 000) will not be
accepted as long as a program with the
same program number as the one started
by the last PIO program start (Input port
000) is running.
Bits 8 to 11: Permission of auto program start when
all-operation-cancellation factor is present
(0: Do not permit, 1: Permit)
Bits 12 to 15: Permission of ON edge of PIO program start
(input port 000) when
all-operation-cancellation factor is present
(0: Do not permit, 1: Permit)
* This parameter specifies an ON edge
acceptance condition and if the start
condition is not satisfied, “Error No. A1E,
start condition nonsatisfaction error” will
generate.
46 Other setting bit pattern 1 2001H 0H ~ FFFFFFFFH
Bits 0 to 3: System reservation (Change prohibited)
Bits 4 to 7: When substituting integer variable in LET /
TRAN Command real number, selection of
round-off of decimal fraction
(0: Not to round off, 1: Round off)
Bits 8 to 11: System reservation
Bits 12 to 15: When indicating TPCD Command = 1,
Selection of process of Sub-routine 1
st
Step
Input Condition Unindicated Command
(0: Not executed, 1: Executed, 2: Error)
