IBM 5150 - Page 341

Game Control Adapter (cont.)
PICs 1300-1
Removal 3-95
Replacement 3-97
Glossary
8-1
H
Heat Sink/Power Transistor Assembly
Locations 5-19
Parts 4-16
Removal 3-62
Replacement 3-63
I
IBM Monochrome Display
Parts 4-8
PICs 400-1
Removal 3-92
Replacement 3-92
IBM Monochrome Display and Parallel Printer Adapter
Locations 5
-11
Parts 4-6
PICs 400-1
Removal 3-95
Replacement 3-97
IBM 80 CPS Matrix Printer
Access Cover
Parts 4-4
Removal 3-32
Base Cover
Locations 5-23
Parts 4-16
Removal 3-33
Replacement 3-34
Carriage Belt
Adjustment 3-35
Locations 5-20
Parts 4-18
Removal 3-37
Replacement 3-40
Carriage Drive Assembly
Locations 5-20
Parts 4-19
9-6
