Step Key Result Notes
10.
OPERATOR MENU
LOCKED
Press both keys at the same time
to relock the Operator Menu.
11.
START
READY Returns the printer to the
READY mode.
HEX DUMP ACTIVE The message HEX DUMP
ACTIVE flashes briefly.
12. A hex code printout results when data is sent to the printer with HEX PRINT MODE enabled. After obtaining
the printout, return to normal print mode by disabling HEX PRINT MODE.
Note: Printing in Hex Mode may alter prior print attributes set by the host computer. A soft reset or power-off may
be required after disabling HEX PRINT MODE.
Figure 16. Sample ASCII Hex Code Printout
Figure 17. Sample Coax Hex Code Printout
Chapter 6. Routine Service and Diagnostics 229
