Table 34. Cabling a Three Node Conguration (continued)
Cable Cable type and length From To
5D 880 mm (2.9
ft)
ND3-P1-T2 ND2-P1-T2
3C 1225 mm (4.01
ft)
ND3-P1-T7 ND1-P1-T1
3D 1225 mm (4.01
ft)
ND3-P1-T8 ND1-P1-T2
5A 1005 mm (3.3
ft)
ND3-P1-T9 ND2-P1-T9
5B 1005 mm (3.3
ft)
ND3-P1-T10 ND2-P1-T10
3A 1225 mm (4.01
ft)
ND3-P1-T15 ND1-P1-T9
3B 1225 mm (4.01
ft)
ND3-P1-T16 ND1-P1-T10
3W 1225 mm (4.01
ft)
ND3-P1-T17 ND1-P1-T23
3X 1225 mm (4.01
ft)
ND3-P1-T18 ND1-P1-T24
5W 1005 mm (3.3
ft)
ND3-P1-T23 ND2-P1-T23
5X 1005 mm (3.3
ft)
ND3-P1-T24 ND2-P1-T24
3Y 1225 mm (4.01
ft)
ND3-P1-T25 ND1-P1-T31
3Z 1225 mm (4.01
ft)
ND3-P1-T26 ND1-P1-T32
5Y 880 mm (2.9
ft)
ND3-P1-T31 ND2-P1-T31
5Z 880 mm (2.9
ft)
ND3-P1-T32 ND2-P1-T32
6C 1005 mm (3.3
ft)
ND2-P1-T7 ND1-P1-T7
6D 1005 mm (3.3
ft)
ND2-P1-T8 ND1-P1-T8
Memory VRMs 267
