Concurrent maintenance circuit card
Removing the concurrent maintenance circuit card from the 9080-M9S
system node
To remove the concurrent maintenance circuit card, complete the steps in this procedure.
Procedure
1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged
into a ground jack or connected to an unpainted metal surface. If not, do so now.
2. Remove the concurrent maintenance circuit card.
a) Unlock the levers (A) to release the concurrent maintenance circuit card from its connector. Refer
to the following image.
b) Rotate the levers in the direction shown.
c) While holding the concurrent maintenance circuit card by its levers, pull upward to remove the card
from its slot.
