Control panel
Preparing the 9080-M9S system to remove and replace the control panel
To prepare the system to remove and replace a control panel, complete the steps in this procedure.
Procedure
1. If a USB device is connected to the USB port on the front of the system control unit, ensure that the
USB device is not being used. Label and remove the USB cable.
2. Attach the electrostatic discharge (ESD) wrist strap.
The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is
completed, and if applicable, until the service access cover is replaced.
Attention:
• Attach an electrostatic discharge (ESD) wrist strap to the front ESD jack, to the rear ESD jack,
or to an unpainted metal surface of your hardware to prevent the electrostatic discharge from
damaging your hardware.
• When you use an ESD wrist strap, follow all electrical safety procedures. An ESD wrist strap is
used for static control. It does not increase or decrease your risk of receiving electric shock
when using or working on electrical equipment.
• If you do not have an ESD wrist strap, just prior to removing the product from ESD packaging
and installing or replacing hardware, touch an unpainted metal surface of the system for a
minimum of 5 seconds. If at any point in this service process you move away from the
system, it is important to again discharge yourself by touching an unpainted metal surface for
at least 5 seconds before you continue with the service process.
Removing the control panel from the 9080-M9S system
To remove a control panel, complete the steps in this procedure.
Procedure
1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged
into a ground jack or connected to an unpainted metal surface. If not, do so now.
2. Access the Advanced System Management Interface (ASMI).
Attention:
During this procedure: Do not reset the service processor, do not remove the service
processor card, and do not power off and power on the system.
3. In the navigation area, select Concurrent maintenance > Control Panel.
4. In the Control Panel window, select the Remove action and press Continue.
5. Verify that the location code C5 for the control panel is selected and then click Save Settings.
6. If the operation was successful, the window displays Operation completed successfully. You can
then remove the control panel.
7. To remove the control panel, complete the following steps:
a) Put your thumb against the front of the latch (A) as shown in the following îš³gure, and put your
index îš³nger against the rear of the latch (B).
b) Push against the latch with your thumb and then pull the latch out with your index îš³nger. This
action releases the latch.
