Removing an NVMe drive backplane from the 9080-M9S system
To remove an NVMe drive backplane from the system, complete the steps in this procedure.
Procedure
1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged
into a ground jack or connected to an unpainted metal surface. If not, do so now.
2. To remove any NVMe U.2 drives from the failed backplane, complete the following steps:
a) Press the release latch (A) in the direction that is shown to release the drive handle (B).
(L007)
CAUTION: A hot surface nearby. (L007)
b) Support the bottom of the NVMe U.2 drive as you slide the drive out of the system, holding the drive
by its sides.
Note: Do not pull the drive out by using the handle.
388
Power Systems: Removing and replacing parts in the 9080-M9S system
