Appendix C. Rack mounting templates
This appendix provides duplicate copies of the rack mounting templates. If you want
to tear out the templates from this document for easier use, use these copies rather
than those provided in “Installing the support rails” on page 33.
Use the following templates (Figure 104 on page 190 and Figure 105 on page 191)
to identify the proper locations for inserting M5 screws when mounting the support
rails and DS4800 in a rack cabinet. The locations for the M5 screws are highlighted
in the templates.
The DS4800 is 4 U high. Align the template with the rack at a U boundary. U
boundaries are shown as horizontal dashed lines in the rack mounting templates.
Note: The mounting holes that are shown in the following templates are square.
The holes in your rack cabinet might be round or square.
© Copyright IBM Corp. 2006, 2007 189
