ds48020
DS4800
FRONT
Rack Mounting
Template
0 U
2 U
3 U 3 U
2 U
1 U1 U
0 U
4 U
4 U
Rail assembly
(Front left)
Rail assembly
(Front right)
Rail assembly
(Front left)
Rail assembly
(Front right)
Figure 104. DS4800 front rack mounting template
190 IBM System Storage DS4800 Storage Subsystem: Installation, User’s, and Maintenance Guide
