Table 13. Weight of expansion enclosure SAS drives
FRU description FRU part number
Approximate weight per unit
kg lb
600 GB 15 K 2.5-inch
hard disk drive
01LJ061 0.304 0.670
1.2 TB 10 K 2.5-inch hard
disk drive
01LJ062 0.304 0.670
1.8 TB 10 K 2.5-inch hard
disk drive
01LJ063 0.304 0.670
6 TB 7.2 K 3.5-inch Near-
Line SAS hard disk drive
01LJ064 0.876 1.931
8 TB 7.2 K 3.5-inch Near-
Line SAS hard disk drive
01LJ065 0.876 1.931
10 TB 7.2 K 3.5-inch
Near-Line SAS hard disk
drive
01LJ066 0.876 1.931
1.6 TB 2.5-inch tier 0
flash drive
01LJ073 0.224 0.494
3.2 TB 2.5-inch tier 0
flash drive
01LJ074 0.224 0.494
1.92 TB 2.5-inch tier 1
flash drive
01LJ075 0.224 0.494
3.84 TB 2.5-inch tier 1
flash drive
01LJ076 0.224 0.494
7.68 TB 2.5-inch tier 1
flash drive
01LJ077 0.224 0.494
15.36 TB 2.5-inch tier 1
flash drive
01LJ078 0.224 0.494
Weight increases as FRUs are installed
The 5U expansion enclosure supports up to 92 SAS drives. As Table 14 on page 47 shows, substantial
weight is added to the enclosure when all drives are installed.
Table 14. Weight of an enclosure with 92 SAS drives
FRU description
Approximate weigh per unit
Maximum
supported
Approximate extra weight
kg lb kg lb
2.5-inch tier 0
flash drive
2.5-inch tier 1
flash drive
0.224 0.494 92 20.608 45.433
2.5-inch hard
disk drive
0.304 0.670 92 27.968 61.659
Chapter 4. Installing an optional 5U SAS expansion enclosure 47
