Table 15. Parts listing, Type 7160 (continued)
Index Description
CRU part
number (Tier 1)
CRU part
number (Tier 2)
Dual-port 10 GbE adapter 81Y9993
6 Gb perform op 90Y4356
Broadcom NetExtreme qp 90Y9355
Broadcom NetExtreme dp 90Y9373
Emulex 10 GbE 95Y3766
Consumable parts
Consumable parts are not covered by the IBM Statement of Limited Warranty. The
following consumable parts are available for purchase from the retail store.
Table 16. Consumable parts, Type 7160
Index Description Part number
11 ServeRAID M5110 series battery kit 81Y4491
To order a consumable part, complete the following steps:
Note: Changes are made periodically to the IBM website. The actual procedure
might vary slightly from what is described in this document.
1. Go to http://www.ibm.com.
2. From the Products menu, select Upgrades, accessories & parts.
3. Click Obtain maintenance parts; then, follow the instructions to order the part
from the retail store.
If you need help with your order, call the toll-free number that is listed on the
retail parts page, or contact your local IBM representative for assistance.
Structural parts
Structural parts are not covered by the IBM Statement of Limited Warranty.
Table 17. Structural parts, Type 7160
Index Description Part number
1 Top cover 00D4437
2 Power supply unit cage, redundant 00D4444
2 Power supply unit cage, fixed 00D4445
4 Filler, power supply 1U 49Y4821
13 Chassis assembly (3.5-inch, without front bezel) 00D4433
13 Chassis assembly (2.5-inch, without front bezel) 00D4440
14 Filler, optical drive 00D4436
17 Front bezel, 3.5-inch 00D4447
18 Front bezel, 2.5-inch 00D4448
19 Filler, 3.5-inch simple-swap 69Y5368
19 Filler, 3.5-inch hot-swap 69Y5364
22 Filler, blank EMC 44T2248
Chapter 5. Parts listing, IBM System x3530 M4 Type 7160 269
