5. Install the cover (see “Replacing the server top cover” on page 67).
6. Reconnect the external cables; then, reconnect the power cords and turn on the
peripheral devices and the server.
Removing the operator information panel assembly
To remove the operator information panel, complete the following steps.
1. Read the safety information that begins on page Safety and “Installation
guidelines” on page 30.
2. Turn off the server (see “Turning off the server” on page 21) and all attached
peripheral devices. Disconnect all power cords; then, disconnect all external
cables as necessary to replace the device.
3. Remove the server cover (see “Removing the server top cover” on page 362).
4. Disconnect the cable from the back of the operator information panel assembly.
5. Push the blue points on the rear of the operator information panel to the front
of the server.
330 System x3530 M4 Type 7160: Installation and Service Guide
