DANGER
Some laser products contain an embedded Class 3A or Class 3B laser
diode. Note the following.
Laser radiation when open. Do not stare into the beam, do not view
directly with optical instruments, and avoid direct exposure to the beam.
7. Touch the static-protective package that contains the new optical drive to any
unpainted metal surface on the server; then, remove the optical drive from the
package and place it on a static-protective surface.
8. Attach the drive retention clip that you removed from the previous drive to
the side of the new drive.
9. Align the drive in the drive bay and slide the drive into the CD/DVD drive
bay until the drive clicks into place.
10. Reconnect the power cord and any cables that you removed.
11. Turn on the peripheral devices and the server.
308 System x3530 M4 Type 7160: Installation and Service Guide

IBM System x3530 M4 Specifications

General

Processor	Intel Xeon E5-2600 series
Memory	Up to 768 GB DDR3
Form Factor	1U Rack
Drive Bays	Up to 8 x 2.5-inch or 4 x 3.5-inch
RAID Support	RAID 0, 1, 5, 10
Network Interface	2 x 1Gb Ethernet
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
