Steps for removing the RAID adapter battery or flash power module for
3.5-inch hard disk drive server models.
a. Press the blue release tabs and rotate the battery or power module holder
upward.
b. Slightly press the retention clip outward to remove the battery or power
module.
Retention clip
Holder
Battery / flash power module
Figure 41. RAID adapter battery or flash power module removal for 2.5-inch hard disk drive
server models
Chapter 5. Removing and replacing components 133
