SAS/SATA power
connector
SAS/SATA
configuration
connector
SAS/SATA configuration
and power cable
SAS/SATA signal
cable
Figure 106. ServeRAID adapter cable routing for four hot-swap 3.5-inch hard disk drive
configuration
Chapter 5. Removing and replacing components 189
