SAS/SATA configuration
and power cable
SAS/SATA signal
cable
SAS/SATA power
connector
SAS/SATA
configuration
connector
Figure 107. ServeRAID adapter cable routing for eight hot-swap 2.5-inch hard disk drive
configuration
190 IBM System x3550 M5 Type 5463: Installation and Service Guide
