IBM x3100 M5 Type 5457

Power connector
Serial 1 (Com1)
USB connectors
Ethernet
connector 1
Video
Ethernet transmit/
receive activity
LED
Ethernet link status
LED
Power switch
Ethernet
connector 2
Ethernet transmit/
receive activity
LED
Ethernet link status
LED
Figure 66. Input/output (I/O) connectors on the rear of 4U server models with non-hot-swap
power supplies
Video
Serial (Com1)
Ethernet
connector 2
USB connectors
AC Power LED (green)
DC power LED (green)
Fault (error)LED (yellow)
Power connectors
Ethernet transmit/
receive activity LED
Ethernet link
status LED
Ethernet
connector 1
Figure 67. Input/output (I/O) connectors on the rear of 5U server models with hot-swap power
supplies
